Please note that bike specifications are subject to change without prior notice.
Frame: Genius Alloy 6061
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork: FOX 36 Float Rhythm Air Grip
3-Modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 160mm travel
Rear Shock: FOX Float Custom EVOL Performace Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 150mm / T185X55mm
Remote System
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Rear Derailleur: Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Shifters: Shimano Deore SL-M6100-R / Rapidfire Plus
Crankset: Praxis Cadet M24HD
55mm CL / 32T
Chainguide: SCOTT custom
BB-Set: Praxis M24 BB92 / shell 41x92mm
Chain: Shimano Deore CN-M6100
Cassette: Shimano Deore CS-M6100-12 / 10-51 T
Brakes: SRAM DB8 4 Piston Disc
Rotor: SRAM Centerline CL Rotors 200/F and 180/R
Handlebar: Syncros Hixon 2.0 Alloy 6061 D.B.
12mm Rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips
H'stem; Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost: Syncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M size 150mm / L & XLsize 170mm
Seat: Syncros Tofino 2.5 Regular
Headset: Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Hub (Front): Formula CL-811 / 15x110mm
Hub (Rear): Formula CL-148M / 12x148mm
Spokes: Stainless Black 15G / 1.8mm
Rims: Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
Front Tire: Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO
Rear Tire: Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO
Extras:
Syncros Fork Fender
Approx weight in KG: 15.5 (Tubeless setup)
Approx weight in LBS: 34.17 (Tubeless setup)
Max. System Weight: 128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
