Please note that bike specifications are subject to change without prior notice
Frame
Aspect 900 series / Alloy 6061 Custom Butted Tubing
BSA73 / Internal Cable Routing / replaceable hanger
Fork
Suntour XCR32/X1-RL-R
Remote Lockout / Reb. Adj.
100mm travel
Remote System
Suntour Remote lockout
Rear Derailleur
Shimano Deore RD-M4120
20 Speed
Front Derailleur
Shimano FD-M4100 Side Swing / 31.8mm
Shifters
Shimano SL-M4100
R-fire plus / 2 way release
Crankset
Shimano FC-M4100-2
2-piece Design / 36X26
BB-Set
Shimano BB-SM-BB52
Hollowtech II / threaded
Chain
KMC X10
Cassette
Shimano CS-M4100-10 / 11-42T
Brakes
Shimano MT200 / Hydr. Disc
Rotor
Shimano SM-RT10 CL / 180/F and 160/R
Handlebar
Syncros 3.0 / 720mm
black / 31.8mm / 12mm rise / 9° BS
Syncros Comfort Lock-on Grip
H'stem
Syncros 3.0 / 7° / Black
Seatpost
Syncros 3.0
31.6mm / 350mm / Black
Seat
Syncros 3.0
Headset
Syncros OE Press Fit / 1 1/8"
OD 50mm / ID 44mm
Hub (Front)
Formula CL51
Hub (Rear)
Shimano FH-TX5058
Spokes
14 G / stainless / black
Rims
Syncros X-20 Disc
32H / black
Front Tire
Kenda Booster
2.4" / 30TPI
Rear Tire
Kenda Booster
2.4" / 30TPI
Pedals
VP VP-536
Approx weight in KG
13.95 (with tubes / wo Pedals)
Approx weight in LBS
30.75 (with tubes / wo Pedals)
Max. System Weight
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
