| Frame Material |
Aluminum |
| Frame Material Details |
Hydroformed high-polished triple-butted alloy; molded chainstay and down tube protection |
| Rear Travel |
140mm |
| Rear Shock |
FOX FLOAT DPS Performance, EVOL, 3-position adjust, custom tune, 210mm x 50mm
Upgrade option: FOX FLOAT DPX2 Factory, EVOL, 3-position adjust, Kashima coating |
| Fork |
FOX FLOAT 34 Performance, GRIP damper, 3-position adjust, 44mm offset
Upgrade options: FOX FLOAT 34 Factory, FIT4 damper, 3-position adjust, Kashima coating, 44mm offset; FOX FLOAT 36 Factory, GRIP2 damper, Kashima coating, 44mm offset |
| Fork Travel |
FOX 34: 140mm
FOX 36: 150mm |
| Head Tube Diameter |
Tapered, 1.125" top, 1.5" bottom |
| Headset |
ACROS, alloy, integrated |
| Handlebar |
OC1, 35mm clamp diameter, 12mm rise, 780mm width
Upgrade option: Race Face Aeffect, 35mm clamp diameter, 20mm rise, 780mm width |
| Stem |
OC1, 3D forged alloy, 35mm bar clamp, 7° rise, 45mm (SM/MD) or 55mm (LG/XL) length
Upgrade option: Race Face Aeffect R, 35mm bar clamp, 40mm (SM/MD) or 50mm (LG/XL) length |
| Grips |
|
| Brakes |
Shimano Deore M6100, 2-piston
Upgrade options: Shimano Deore XT M8120, 4-piston, Shimano Deore M6120, 4-piston |
| Brake Levers |
Shimano Deore M6100
Upgrade options: Shimano Deore XT M8120, Shimano Deore M6120 |
| Drivetrain |
1x |
| Shifters |
Shimano SLX M7100, 12-speed, I-SPEC EV bracket |
| Front Derailleur |
None |
| Rear Derailleur |
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+ |
| ISCG Tabs |
None |
| Chainguide |
None |
| Cranks |
Race Face Aeffect
Length: 170mm (SM/MD), 175mm (LG/XL) |
| Chainrings |
Race Face Aeffect, 32 tooth |
| Bottom Bracket |
73mm BSA threaded |
| Pedals |
None |
| Chain |
Shimano Deore M6100, 12-speed |
| Cassette |
Shimano SLX M7100, 12-speed, 10-51 tooth |
| Rims |
Race Face AR 30c wheelset, TLR
Upgrade option: DT Swiss M-1900 Spline 30c wheelset |
| Hubs |
Race Face AR 30c wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Upgrade option: DT Swiss M-1900 Spline 30c wheelset |
| Spokes |
Race Face AR 30c wheelset
Upgrade option: DT Swiss M-1900 Spline 30c wheelset |
| Tires |
Front: Maxxis High Roller II, Dual compound, EXO, TR, 60 TPI, 29" x 2.5"
Rear: Maxxis Rekon, Dual compound, EXO, TR, 60 TPI, 29" x 2.4"
Front upgrade option: Maxxis Minion DHF, 29" x 2.5"
Rear upgrade option: Maxxis Minion DHR II, 29" x 2.4" |
| Saddle |
fi'zi:k Taiga S, alloy rails
Upgrade option: fi'zi:k Taiga, Kium rails |
| Seatpost |
OC2 dropper; 125mm (SM), 150mm (MD/LG), or 170mm (XL) drop |
| Seatpost Diameter |
31.6mm |
| Seatpost Clamp |
Single bolt |
| Rear Dropout / Hub Dimensions |
148x12mm Boost |
