Full suspension or entirely rigid, upon a mountain top or deep in the woods, it’s up to you to define your trail. Our new Mallet Trail pedal fills the missing piece in our clip-in range, sitting perfectly between our Candy and Mallet E pedals. Equipped with a long spindle for stability and speed, two adjustable pins per side for added traction, and our eggbeater system with 4-sided entry and superior mud shedding, the Mallet Trail is ready to join you on your next adventure.
- Optimized platform size and surface for trail/gravel riding
- Long spindle, 57mm q-factor for more shoe clearance and stability at speed
- Integrated traction pad technology to customize and optimize the shoe/pedal interface
- 2 adjustable pins per side for grip
- Hex alloy endcap for durability
- 4-sided entry / superior mud shedding
- Customizable float & release angle
| Body Material |
6061-T6 Aluminum |
| Body Dims (L x W) |
78mm x 74mm |
| Wing Material |
17-4PH Stainless |
| Spindle Length |
57mm |
| Traction Pins |
2 adjustable per side |
| Pin Length |
8mm |
| Inner Bearing Type |
Igus LL-glide bearing |
| Outer Bearing Type |
Enduro MAX cartridge bearing |
| Endcap |
Hex alloy |
| Spindle Material |
Forged SCM 435 Chromoly Steel |
| Spring Material |
300 series stainless steel |
| Max Rider Weight |
No restriction |
| Weight |
344g per pair |
| Included Cleat Type |
15° / 20° Standard Release, 6° Float |
| Cleat Notice |
Third-party cleats are not approved for use with Crankbrothers pedal systems. Using non-Crankbrothers cleats can reduce pedal lifespan and voids the pedal warranty. |
